Magnum Peak
The Magnum Peak comes packed with power. High torque for great climbing abilities and up to 25 MPH pedal assist for fast on and off road riding. The sleek design and high-end components will turn heads. Available with a 27.5″ or a 29″ wheel. One year comprehensive warranty.
$2,099.00
Why Buy at a Local Bike Bike?
Free Adjustments for Life
Any bike you buy from Bike Shop California or Bike Shop Santa Monica comes with free adjustments for life from the orginal owner.
Real Expert Bike Advice
We could probably make more money doing something else…but we are passionate about bikes. That means are up to date on the current trends and bikes as well as what is coming next.
Support Local Business
We are a local business creating real jobs in the community and supporting the idea of pollution free mobility. Money purchased at local businesses go directly back to supporting local economies.
Magnum Peak Product Details
Description
Model:
Magnum Peak
Body Position:
Forward
Electric Bike Class:
Throttle On-demand (Class 2), Speed Pedelec (Class 3)
*Throttle can be removed for Class 1
Warranty:
1 Year Comprehensive
Max Load:
265lbs
Electronic Details
Motor Type:
Das-kit R4 Rear Geared Hub Motor
Motor Output:
48v 500w
Battery Voltage / Amp Hours / Watt Hours:
48v / 13ah / 624wh / With Usb Port
Battery Chemistry:
Lithium Nickel Cobalt Manganese (Li-ncm)
Estimated Charge Time:
6.5 Hrs
Estimated Min And Max Range:
30 To 60 Miles (Depending On Riding Style, Terrain, Rider Weight And Peddle Assist Level.)
Display Type:
Das-kit C7, Fixed, Backlit, Monochrome Lcd
Display Records:
Power Output Indicator(6 Bars), Battery Level (6 Bars), Speed, Assist Level (0-6), Odometer, Trip Distance, Trip Time, Battery Voltage
Drive Modes:
Cadence Sensing Pedal Assist, Trigger Throttle, Walk Mode
Top Speed:
25mph With Pedal Assist, 20mph Throttle Only
Bicycle Details
Total Weight:
59lbs
Battery Weight:
9lbs
Frame Type:
High Step
Frame Material:
6061 Aluminum Alloy
Fork Details:
Sr Suntour Xcm Spring Suspension, 100mm Travel, Compression Adjustment, Lockout
Attachment Points:
Rear Rack Bosses, Fender Bosses, Bottle Cage Bosses
Gearing Details:
24 Speed 3×8, Shimano Altus Front Derailleur, Shimano Acera Rear Derailleur 11-32t Rear Cassette
Shifter Details:
Shimano Altus Speed Trigger Shifter
Cranks:
Shimano 28-33-42t Chainring, 170mm, Square Taper Bottom Bracket
Pedals:
Wellgo Aluminum Platform, B087
Stem:
Promax, 110 Mm Length, Aluminum Alloy
Brake Details:
Tektro Auriga Hydraulic Disc Brakes With Motor Inhibitors, 180 Mm Rotors
Grips:
Velo Flat Rubber With Lockers
Saddle:
Promax
Seatpost / Seatpost Dimensions:
Promax, 30.9 X 350mm
Rims:
Aluminum Alloy, Double Walled, 36 Hole
Tires:
Schwalbe Smart Sam, Reflective Sidewall Stripe, Kevlar Lined, Schrader Valve
Wheel Size:
27.5″ (29″) X 2.25
Peak 27.5″ Measurements
| Max Seat Height *Measured from bottom of pedal stroke | 37″ |
| Min Seat Height *Measured from bottom of pedal stroke | 30″ |
| Seat Tube | 20″ |
| Handlebar Height | 43″ |
| Handlebar Width | 27.5″ |
| Standover Height | 30.5″ |
| Total Length | 68″ |
| Wheelbase | 45″ |
Peak 29″ Measurements
| Max Seat Height *Measured from bottom of pedal stroke | 40″ |
| Min Seat Height *Measured from bottom of pedal stroke | 32″ |
| Seat Tube | 20.75″ |
| Standover Height | 30.5″ |
| Total Length | 73.75″ |
