Qualisports Qualibike Dolphin 20 Inch Folding Bike
Introducing the 20inch Wider Tire DOLPHIN by QualiSports.
- It’s a high quality, lightweight bike at a surprisingly affordable price.
- Its portability makes the DOLPHIN ideal for trips that include a stretch by bus or train – perfect for multi-modal urban transport.
- Powerful 350W Geared Hub Motor Drive
- Samsung 36V 14Ah Battery, 50+ Miles Range
- Free Fenders /Head Light/ Rear Light/ Bell/ Tool Bag /Thumb Throttle / Kick Stand
The Dolphin can be ridden in four different modes:
As a normal bike, (PAS) Pedal Assist mode, Cruise control mode, or enjoy an effortless riding experience with a simple press of a trigger throttle to help you get over a hill.
The Dolphin has an efficient and strong 350W brushless geared motor which will assist you to overcome an 18-degree climb effortlessly. Our patented stylish and stealthy seat post design is practical and hides our batteries (Samsung 36V 14Ah). The Dolphin will give the Quali-biker’s 50 mile range on a single charge.
Per Charge (optimal conditions)
|Motor: MXUS Brushless geared DC motor||Brakes: 160mm disc brakes|
|Model name: QSEB 03||Rated output power: 350W||Rim: 20 inch Al-Alloy 12G36H|
|Motor efficiency: ≥85%||Tire: 20×2.35″|
Folding Size: 32.6*18.9*27.5inch
|Rated RPM: 310±10r/min||Chain wheel: Prowheel 52T|
|Rated voltage: 48V||Free wheel: Shimano 14-28T|
|Net weight: 50lbs||Max torque: 40N.m||Derailleur: Shimano 7 speed|
|Range: 62.5Miles（PAS）||Overcurrent protection: 15±1A||Chain: KMC|
|Max. load: 300lbs||Low-voltage protection: 30±1V||Handle bar: Promax|
|Max. speed: 20MPH||Kwh: ≤1.2Kw.h||Display: Kunteng LCD|
|Charging time: 6~7 Hrs||Modes: 5 levels||Controller: Kunteng sine wave FOC|
|Battery type: Samsung Lithium-ion||Tire diameter: 20×2.35 Inch||Brake levers: Al-Alloy e-bike lever|
|Battery capacity: 36V 14Ah||Frame: 20 inch 6061 Al-Alloy Foldable||Saddle: KNUS|
|Noise : ≤ 62 dB(A)||Front fork: 20 inch 6061 Al-Alloy||Pedal: Foldable Pedals|
Intergraded multi-function LCD display
Together with a 12 dots Cadence Sensor to help the riding experience more enjoyable. The LCD panel has the following visual indicators on it. 5 levels of PAS (Pedals Assist levels – 5 levels), battery level indicator, timer, speed, distance, average speed, trip distance, trip timer, ODO, max speed, battery voltage indicator, Lamp on/off, back lights, walking mode and cruise control mode.
